Description
Description
The Fronius GEN24 Plus SC allows the most flexibility for residential customers on the market.
The "SC" identifier stands for Superior Current, denoting an upgraded model line engineered to handle higher DC input currents from next-generation solar panels.
The GEN24 plus has a new feature called 'PV point' which allows a 3 pin plug to provide backup power direct from the solar panels in the event of a blackout.
The GEN24 Plus SC leaves very little to be desired with numerous features such as energy management functions, WLAN connection as standard, Ethernet connectivity and easy integration of third-party components. Thanks to a selection of backup power options (PV Point, full backup) in particular, it ensures the highest degree of power supply reliability.
Features
Key Upgrades vs Standard GEN24 Plus
- Higher PV Input Current: Specifically designed to match high-current TOPCon, HJT, and Back-Contact modules. It accommodates a larger amount of modern high-performance solar panels without throttling power.
- Integrated Safety: Comes equipped with the Fronius Arc Guard (AFCI) to automatically detect and extinguish dangerous DC arc faults before fire hazards develop.
- Enhanced Battery Flexibility: Expands energy storage capabilities with optimised support for up to 4 high-voltage battery modules (such as the Fronius Reserva series) at higher operating voltages.
- Fronius Solar.Web
- With Solar.web, you can always keep an eye on your electricity consumption. All the information you need is available anytime, anywhere and you will be notified of any important events.-----
- Did you know you can design your PV System with Fronius?! Fronius Solar.creator - the perfect design tool! Dimension your photovoltaic system using the latest solar modules and all available Fronius inverters!
- See for yourself! - Fronius Solar.creator
- AC attributes
- Max power
- 5000W
- Max current
- 22.7A
- Number of phases
- 1
- EPS power
- 3kW PV point, 3kw on battery
- DC attributes
Panels
- Number of MPPT
- 2
- V range of MPPT
- 65 - 530V
- Max power - Max current
- 7500W - 33A/18A
- Max voltage
- 600V
- Start up voltage
- 80V
Batteries
- Max power
- 3000W
- Max current
- 22A
- Battery types
- Lithium
- Battery voltage range
- 150 - 455V
Technical Specifications
| AC attributes | Max power |
|---|---|
| Number of phases | 1 |
| EPS power | 3kW PV point, 3kw on battery |
| DC attributes | 2 |
| Panels | : V range of MPPT |
| Number of MPPT | 65 - 530V |
| Start up voltage | 80V |
| Batteries | : Max power |
| Battery types | 150 - 455V |
| Lithium | Max efficiency |
| Battery voltage range | 97.6% |
| IP rating | IP66 |
| DC switch, reverse polarity, DC insulation measurement | Export limitations |
| Weight | 15.4kg |
| Dimensions | 530x474x165mm |
| Communication | Wifi, Ethernet, 6 IO pins, USB 2.0 |
| Key features | Supports export control |
| Wide PV voltage range | IP66 protection class |
| PV point | Compatible Batteries: Fronius Reserva & BYD Battery-Box HVS/HVM, HVS+/HVM+ & LG FLEX |
Additional Notes
- 5000W
- Max current
- 22.7A
- Max power - Max current
- 7500W - 33A/18A
- Max voltage
- 600V
- 3000W
- 22A
- Built in protection
- Possible using meter
- Warranty (extensions)
- 10 years (15 years extensions available)
- Dynamic peak manager for accurate MPP tracking
- Active cooling
