Victron Smart IP43 Battery Charger 24V/25A/120-240V 3 Output

Overview

This adaptive 5-step Phoenix Smart Ip43 charger 24/25(3) can provide either 30A or 50A of charge to each of three battery banks. Or the Phoenix 1+1 model provides 3A to the starter-battery, the rest to the ‘house’ bank. 24V models are available with 16A/25A charge. Bluetooth built-in so it can be programmed from your phone or tablet using Victron Connect. Its VE Direct port means you can connect it to a Cerbo GX. Its remote port means you can control it from a BMS. Its relay port means you can control external devices from it (only while connected to AC power). It has a 6 stage charge algorithm with storage mode for conventional batteries and a 3 stage algorithm for Lithium batteries. Its IP rating gives it limited protection from sprayed water.

Description

85-265 volt input, 45-65 Hz, 24 volt 25 amp three outputs.
Power Factor >0.99
Fully programmable charge algorithm accessed via a phone, tablet, Mac or PC using Bluetooth and /or VE Direct using the Victron Connect App
6 Stage charge algorithm for conventional batteries, 3 stage for lithium batteries
IEC 320 C14 inlet with retainer clip
Charge current 25 amps with low current mode of 12.5 amps available if needed
Programmable relay
VE Direct port
Remote on-off
Suitable for use with Li Ion batteries
Can be used as a power supply with a fixed output voltage

Features

• Manufacturer
• Victron Energy
• Commodity Code
• 85044060
• Dimensions (mm) (H x W x D)
• 245 x 275 x 145
