Description
Short Description
Rating: 460W
Efficiency: 23%
Width: 1,134mm
Height: 1,762mm
Price per Watt: (14.9c/Wp)
Description
These modules are operated with the latest MBB n-type solar cell and half-cell configuration, featuring higher output power, lower LID, better response to low light, and an improved temperature coefficient.
Higher power generation, better LCOE
n-type with lower LID
Better response to low light
Improved temperature coefficient
Note: 1200mm "landscape" cable included
Features
Specifications
| Supplier Part No | JAM54D-41-460-LR-TS-AB-MC4 |
|---|---|
| Weight | 22 kg |
| Rated Power | 460 W |
| Length | 1,762 mm |
| Width | 1,134 mm |
| Depth | 30 mm |
| VMPP | 33.68 V |
| IMPP | 13.66 A |
| Isc | 14.43 A |
| Voc | 40.6 V |
| Temp. Coefficient (Mpp) | -0.29 % |
| Clamp position on panel | Long and short side |
| Connector Description | EVO2A |
| Connector Type | Round Post |
| Efficiency | 23.0 % |
| Pallet Size | Oversized |
